Fiber Laser Marking for printing on metal and aluminum lids, cans,
bottles and other containers
Fly fiber Laser Marking machine is use for mark on Coding and
marking extrusion products, expiry date on plastic , expiry date on
rubber, expiry date on metal can,expriy date on foil pouch
bag,Coding and marking on extruded materials
When deciding which laser marking machines are best suited for your
needs, there are several factors to consider. First and foremost is
your budget, as these machines can vary significantly in price.
Additionally, you’ll want to take into account any special features
you may need, such as speed control or software compatibility.
Finally, you should think about how you plan on laser marking metal
parts. Additional factors, like focal distance and the geometry of
your part, will play an important role in your laser marking set
up. However, the 3-Axis Hybrid Laser Marker can eliminate these
types of factors as a concern.
Feature
Laser tube life of over 100,000 hours – less downtime
Fine spot size for high quality codes
Two beam orientation options allows coding in any direction
Choice of 4 lenses for codes tailored to your requirements
Compact marking head for easy integration into moving and static
lines
Internal air cooling system for increased efficiency and less
maintenance
Quick message creation reduces time spent on setup and changeovers
Extremely efficient use of the laser with no compromise on code
quality or speed
project | Parametertable | 20W | 30W |
characteristic | Machine material | All aluminum sandblasting oxidation |
Laser | The service life is more than 100000 hours |
Laser wavelength | 1064nm |
output power | ≥23W | ≥34W |
Marking speed | ≤12000mm/s |
controller | 10.2 inch touch controller |
Cooling system | Air cooling |
parameter | Focus lens | 165mm |
Minimum linewidth | 0.012mm |
Repetitionaccuracy | 0.003mm |
Marking range | 110mm*110mm(optinal) |
Positioning mode | Blue light indication |
Number of rows | Any line within the marking range |
Production line speed | 0~130m/min (depending on the material) |
Software | Multilingual | English, Spanish, German, Chinese, Russian, Arabic, etc |
jurisdiction | Multi user management authority |
operating system | Linuxsystem |
Inkjet mode | Static, analog, encoder |
Reserved signal | Start, print status, finish, fault |
data protection | With power failure data protection energy |
monitor | Provide overspeed alarm function |
De crossing | Automatic removal of intersections |
Coding software | Single and double machine code sending |
Support type | typeface | Chinese and English, numbers, traditional, etc |
file format | BMP/DXF/HPGL/JPEG/PLT |
bar code | CODE39,CODE128,CODE126,QR |
Servicing parameters | Power Supply | 220V/50HZ |
Power consumption | 400W |
Net weight of machine | 38kg |
Overall dimension | 530mmX140mmX165mm |
environment | requirement | External temperature0℃－45℃;humidity≤95 |
